Run Archivist

As for now, Archivist is implemented only in Nim and can be found in archivist-node repository.

It is a command-line application which may be run in a different ways:

Using binary
Run as a service in Linux
Run as a service in Windows (not supported yet)
Using Docker
Using Docker Compose
On Kubernetes

During the run, it is required to pass configuration option to the application, which can be done in a different ways.

Configuration

It is possible to configure Archivist node in several ways:

CLI options
Environment variables
Configuration file

The order of priority is the same as above:
CLI options --> Environment variables --> Configuration file.

Common information

Units

For some configuration options, we can pass values in common units like following:

shell

--cache-size=1m/1M/1mb/1MB
--storage-quota=2m/2M/2mb/2MB

--block-mi=1s/1S/1m/1M/1h/1H/1d/1D/1w/1W
--block-ttl=2s/2S/2m/2M/2h/2H/2d/2D/2w/2W

Logging

Archivist uses Chronicles logging library, which allows great flexibility in working with logs. Chronicles has the concept of topics, which categorize log entries into semantic groups.

Using the log-level parameter, you can set the top-level log level like --log-level="trace", but more importantly, you can set log levels for specific topics like --log-level="info; trace: marketplace,node; error: blockexchange", which sets the top-level log level to info and then for topics marketplace and node sets the level to trace and so on.

And one useful example, to get most important data for debugging

shell

--log-level="trace; warn:discv5,providers,manager,cache,libp2p,multistream,switch,transport,tcptransport,semaphore,asyncstreamwrapper,lpstream,mplex,mplexchannel,noise,bufferstream,mplexcoder,secure,chronosstream,connection,connmanager,websock,ws-session,dialer,muxedupgrade,upgrade,identify,contracts,clock,archivist,pendingblocks,peerctxstore,discoveryengine,blockexcengine,blockexcnetwork,blockexcnetworkpeer,JSONRPC-CLIENT,JSONRPC-HTTP-CLIENT"

CLI options

shell

archivist --help

Usage:

archivist [OPTIONS]... command

The following options are available:

     --config-file          Loads the configuration from a TOML file [=none].
     --log-level            Sets the log level [=info].
     --log-format           Specifies what kind of logs should be written to stdout (auto, colors, nocolors,
                            json) [=auto].
     --metrics              Enable the metrics server [=false].
     --metrics-address      Listening address of the metrics server [=127.0.0.1].
     --metrics-port         Listening HTTP port of the metrics server [=8008].
 -d, --data-dir             The directory where the node will store configuration and data.
 -i, --listen-addrs         Multi Addresses to listen on [=/ip4/0.0.0.0/tcp/0].
     --nat                  Specify method to use for determining public address. Must be one of: any, none,
                            upnp, pmp, extip:<IP> [=any].
 -u, --disc-port            Discovery (UDP) port [=8090].
     --net-privkey          Source of network (secp256k1) private key file path or name [=key].
 -b, --bootstrap-node       Specifies one or more bootstrap nodes to use when connecting to the network.
     --max-peers            The maximum number of peers to connect to [=160].
     --num-threads          Number of worker threads ("0" = use as many threads as there are CPU cores
                            available) [=DefaultThreadCount].
     --agent-string         Node agent string which is used as identifier in network [=Archivist Node].
     --api-bindaddr         The REST API bind address [=127.0.0.1].
 -p, --api-port             The REST Api port [=8080].
     --api-cors-origin      The REST Api CORS allowed origin for downloading data. '*' will allow all
                            origins, '' will allow none. [=Disallow all cross origin requests to download
                            data].
     --repo-kind            Backend for main repo store (fs, sqlite, leveldb) [=fs].
 -q, --storage-quota        The size of the total storage quota dedicated to the node [=$DefaultQuotaBytes].
 -t, --block-ttl            Default block timeout in seconds - 0 disables the ttl [=$DefaultBlockTtl].
     --block-mi             Time interval in seconds - determines frequency of block maintenance cycle: how
                            often blocks are checked for expiration and cleanup [=$DefaultBlockInterval].
     --block-mn             Number of blocks to check every maintenance cycle [=1000].
 -c, --cache-size           The size of the block cache, 0 disables the cache - might help on slow hardrives
                            [=0].

Available sub-commands:

archivist persistence [OPTIONS]... command

The following options are available:

     --eth-provider         The URL of the JSON-RPC API of the Ethereum node [=ws://localhost:8545].
     --eth-account          The Ethereum account that is used for storage contracts.
     --eth-private-key      File containing Ethereum private key for storage contracts.
     --marketplace-address  Address of deployed Marketplace contract.
     --validator            Enables validator, requires an Ethereum node [=false].
     --validator-max-slots  Maximum number of slots that the validator monitors [=1000].
                            If set to 0, the validator will not limit the maximum number of slots it
                            monitors.
     --validator-groups     Slot validation groups [=ValidationGroups.none].
                            A number indicating total number of groups into which the whole slot id space
                            will be divided. The value must be in the range [2, 65535]. If not provided, the
                            validator will observe the whole slot id space and the value of the
                            --validator-group-index parameter will be ignored. Powers of twos are advised
                            for even distribution.
     --validator-group-index  Slot validation group index [=0].
                            The value provided must be in the range [0, validatorGroups). Ignored when
                            --validator-groups is not provided. Only slot ids satisfying condition [(slotId
                            mod validationGroups) == groupIndex] will be observed by the validator.
     --reward-recipient     Address to send payouts to (eg rewards and refunds).

Available sub-commands:

archivist persistence prover [OPTIONS]...

The following options are available:

 -cd, --circuit-dir          Directory where the node will store proof circuit data [=data/circuits].
     --circom-r1cs          The r1cs file for the storage circuit [=data/circuits/proof_main.r1cs].
     --circom-wasm          The wasm file for the storage circuit [=data/circuits/proof_main.wasm].
     --circom-zkey          The zkey file for the storage circuit [=data/circuits/proof_main.zkey].
     --circom-no-zkey       Ignore the zkey file - use only for testing! [=false].
     --proof-samples        Number of samples to prove [=5].
     --max-slot-depth       The maximum depth of the slot tree [=32].
     --max-dataset-depth    The maximum depth of the dataset tree [=8].
     --max-block-depth      The maximum depth of the network block merkle tree [=5].
     --max-cell-elements    The maximum number of elements in a cell [=67].

Environment variables

In order to set a configuration option using environment variables, first find the desired CLI option and then transform it in the following way:

prepend it with ARCHIVIST_
make it uppercase
replace - with _

For example, to configure --log-level, use ARCHIVIST_LOG_LEVEL as the environment variable name.

WARNING

Some options can't be configured via environment variables for now ^[1] ^[2].

Configuration file

A TOML configuration file can also be used to set configuration values. Configuration option names and corresponding values are placed in the file, separated by =. Configuration option names can be obtained from the archivist --help command, and should not include the -- prefix. For example, a node's log level (--log-level) can be configured using TOML as follows:

toml

log-level = "trace"

For option, like bootstrap-node and listen-addrs which accept multiple values we can specify data as an array

toml

listen-addrs = [
  "/ip4/0.0.0.0/tcp/1234",
  "/ip4/0.0.0.0/tcp/5678"
]

The Archivist node can then read the configuration from this file using the --config-file CLI parameter, like:

shell

archivist --config-file=/path/to/your/config.toml

Please check Run as a service in Linux for a full example of configuration file.

Auto-discovery

Archivist support marketplace contract auto-discovery based on the chain id, this mapping is done in the source code. In that way we can skip --marketplace-address argument and use it just to override a discovered value.

Run

Basically, we can run Archivist in three different modes:

Archivist node - useful for local testing/development and basic/files sharing.
Archivist node with marketplace support - you can share files and buy the storage, this is the main mode and should be used by the end users.
Archivist storage node - should be used by storage providers or if you would like to sell your local storage.

We also will touch in some words Archivist bootstrap node.

Using binary

Archivist node

We can run Archivist in a simple way like following:

shell

archivist

But, it will use a default data-dir value and we can pass a custom one:

shell

archivist --data-dir=datadir

This will run Archivist as an isolated instance, and if we would like to join an existing network, it is required to pass a bootstrap node. We can pass multiple nodes as well:

shell

archivist \
  --data-dir=datadir \
  --bootstrap-node=spr:CiUIAhIhA5mg11LZgFQ4XzIRb1T5xw9muFW1ALNKTijyKhQmvKYXEgIDARpJCicAJQgCEiEDmaDXUtmAVDhfMhFvVPnHD2a4VbUAs0pOKPIqFCa8phcQl-XFxQYaCwoJBE4vqKqRAnU6GgsKCQROL6iqkQJ1OipHMEUCIQDfzVYbN6A_O4i29e_FtDDUo7GJS3bkXRQtoteYbPSFtgIgcc8Kgj2ggVJyK16EY9xi4bY2lpTTeNIRjvslXSRdN5w \
  --bootstrap-node=spr:CiUIAhIhAhmlZ1XaN44zPDuORyNJV8I79x2eSXt5-9AirVagKCAIEgIDARpJCicAJQgCEiECGaVnVdo3jjM8O45HI0lXwjv3HZ5Je3n70CKtVqAoIAgQ_OfFxQYaCwoJBAWhGBORAnVEGgsKCQQFoRgTkQJ1RCpHMEUCIQCgqSYPxyic9XmOcQYtJDKNprK_Uokz2UzjVZRnPYpOgQIgQ8m96ukov4XZG-j-XH53_vuoy3GkHuneUZ1Xe0luCxk

IMPORTANT

Make sure you are using a proper value for the network you would like to join.

Also, to make your Archivist node accessible for other network participants, it is required to specify a public IP address which can be used to access your node:

shell

archivist \
  --data-dir=datadir \
  --bootstrap-node=spr:CiUIAhIhA5mg11LZgFQ4XzIRb1T5xw9muFW1ALNKTijyKhQmvKYXEgIDARpJCicAJQgCEiEDmaDXUtmAVDhfMhFvVPnHD2a4VbUAs0pOKPIqFCa8phcQl-XFxQYaCwoJBE4vqKqRAnU6GgsKCQROL6iqkQJ1OipHMEUCIQDfzVYbN6A_O4i29e_FtDDUo7GJS3bkXRQtoteYbPSFtgIgcc8Kgj2ggVJyK16EY9xi4bY2lpTTeNIRjvslXSRdN5w \
  --nat=any

TIP

We can set public IP using curl and IP lookup service, like ip.archivist.storage.

After that, node will announce itself using your public IP, default UDP (discovery) and dynamic TCP port (data transfer), which can be adjusted in the following way:

shell

archivist \
  --data-dir=datadir \
  --bootstrap-node=spr:CiUIAhIhA5mg11LZgFQ4XzIRb1T5xw9muFW1ALNKTijyKhQmvKYXEgIDARpJCicAJQgCEiEDmaDXUtmAVDhfMhFvVPnHD2a4VbUAs0pOKPIqFCa8phcQl-XFxQYaCwoJBE4vqKqRAnU6GgsKCQROL6iqkQJ1OipHMEUCIQDfzVYbN6A_O4i29e_FtDDUo7GJS3bkXRQtoteYbPSFtgIgcc8Kgj2ggVJyK16EY9xi4bY2lpTTeNIRjvslXSRdN5w \
  --nat=any \
  --disc-port=8090 \
  --listen-addrs=/ip4/0.0.0.0/tcp/8070

In that way, node will announce itself using specified multiaddress and we can check that via API call:

shell

curl -s localhost:8080/api/archivist/v1/debug/info | jq -r '.announceAddresses'

json

[
  "/ip4/<your public IP>/tcp/8070"
]

Basically, for P2P communication we should specify and configure two ports:

#	Protocol	Function	CLI option	Example
1	UDP	Discovery	`--disc-port`	`--disc-port=8090`
2	TCP	Transport	`--listen-addrs`	`--listen-addrs=/ip4/0.0.0.0/tcp/8070`

And, also it is required to setup port-forwarding on your Internet router, to make your node accessible for participants.

So, a fully working basic configuration will looks like following:

shell

archivist \
  --data-dir=datadir \
  --bootstrap-node=spr:CiUIAhIhA5mg11LZgFQ4XzIRb1T5xw9muFW1ALNKTijyKhQmvKYXEgIDARpJCicAJQgCEiEDmaDXUtmAVDhfMhFvVPnHD2a4VbUAs0pOKPIqFCa8phcQl-XFxQYaCwoJBE4vqKqRAnU6GgsKCQROL6iqkQJ1OipHMEUCIQDfzVYbN6A_O4i29e_FtDDUo7GJS3bkXRQtoteYbPSFtgIgcc8Kgj2ggVJyK16EY9xi4bY2lpTTeNIRjvslXSRdN5w \
  --nat=any \
  --disc-port=8090 \
  --listen-addrs=/ip4/0.0.0.0/tcp/8070 \
  --api-cors-origin="*"

After node is up and running and port-forwarding configurations was done, we should be able to Upload a file/Download a file in the network using API.

You also can use Archivist App UI for files upload/download.

And to be able to purchase a storage, we should run Archivist node with marketplace support.

Archivist node with marketplace support

Marketplace support permits to purchase the storage in Archivist network. Basically, we should add just a persistence sub-command and required CLI options to the previous run.

For a daily use, we should consider to run a local blockchain node based on the network you would like to join. That process is described in the Join Archivist Testnet guide, but for a quick start we can use a public RPC endpoint.

Create a file with ethereum private key and set a proper permissions:

CAUTION

Please use key generation service for demo purpose only.

shell

response=$(curl -s https://key.archivist.storage)
awk -F ': ' '/private/ {print $2}' <<<"${response}" > eth.key
awk -F ': ' '/address/ {print $2}' <<<"${response}" > eth.address
chmod 600 eth.key

Show your ethereum address:

shell

cat eth.address

0x412665aFAb17768cd9aACE6E00537Cc6D5524Da9

Fill-up your ethereum address with ETH and Tokens based on the the network you would like to join.
Specify bootstrap nodes based on the network you would like to join.

Run the node:

shell

archivist \
  --data-dir=datadir \
  --bootstrap-node=spr:CiUIAhIhA5mg11LZgFQ4XzIRb1T5xw9muFW1ALNKTijyKhQmvKYXEgIDARpJCicAJQgCEiEDmaDXUtmAVDhfMhFvVPnHD2a4VbUAs0pOKPIqFCa8phcQl-XFxQYaCwoJBE4vqKqRAnU6GgsKCQROL6iqkQJ1OipHMEUCIQDfzVYbN6A_O4i29e_FtDDUo7GJS3bkXRQtoteYbPSFtgIgcc8Kgj2ggVJyK16EY9xi4bY2lpTTeNIRjvslXSRdN5w \
  --nat=any \
  --disc-port=8090 \
  --listen-addrs=/ip4/0.0.0.0/tcp/8070 \
  --api-cors-origin="*" \
  persistence \
  --eth-provider=https://rpc.testnet.archivist.storage \
  --eth-private-key=eth.key

NOTE

We could skip --marketplace-address argument and rely on marketplace contract Auto-discovery.

After node is up and running, and your address has founds, you should be able to Purchase storage using API.

You also can use Archivist App UI for storage purchase.

Archivist storage node

Archivist storage node should be run by storage providers or in case you would like to sell your local storage.

For that, additionally to the Archivist node with marketplace support we should use prover sub-command and required CLI options.

That sub-command will make Archivist to listen for a proof requests on the blockchain and answer them. To compute an answer for the proof request, Archivist will use stored data and circuit files generated by the code in the archivist-storage-proofs-circuits repository.

Every network uses its own generated set of the files which are stored in the archivist-contracts repository and also uploaded to the CDN. Hash of the files set is also known by the marketplace smart contract.

To download circuit files and make them available to Archivist app, we have a stand-alone utility - cirdl. It can be compiled from the sources or downloaded from the GitHub release page.

Create ethereum key file

example

CAUTION

Please use key generation service for demo purpose only.

shell

response=$(curl -s https://key.archivist.storage)
awk -F ': ' '/private/ {print $2}' <<<"${response}" > eth.key
awk -F ': ' '/address/ {print $2}' <<<"${response}" > eth.address
chmod 600 eth.key

Show your ethereum address:

shell

cat eth.address

0x412665aFAb17768cd9aACE6E00537Cc6D5524Da9

To download circuit files, we should pass directory, RPC endpoint and optionally marketplace address to the circuit downloader:

shell

# Create circuit files folder
mkdir -p datadir/circuits
chmod 700 datadir/circuits

# Download circuit files
cirdl \
  datadir/circuits \
  https://rpc.testnet.archivist.storage

Start Archivist storage node

shell

archivist \
  --data-dir=datadir \
  --bootstrap-node=spr:CiUIAhIhA5mg11LZgFQ4XzIRb1T5xw9muFW1ALNKTijyKhQmvKYXEgIDARpJCicAJQgCEiEDmaDXUtmAVDhfMhFvVPnHD2a4VbUAs0pOKPIqFCa8phcQl-XFxQYaCwoJBE4vqKqRAnU6GgsKCQROL6iqkQJ1OipHMEUCIQDfzVYbN6A_O4i29e_FtDDUo7GJS3bkXRQtoteYbPSFtgIgcc8Kgj2ggVJyK16EY9xi4bY2lpTTeNIRjvslXSRdN5w \
  --nat=any \
  --disc-port=8090 \
  --listen-addrs=/ip4/0.0.0.0/tcp/8070 \
  persistence \
  --eth-provider=https://rpc.testnet.archivist.storage \
  --eth-private-key=eth.key \
  prover \
  --circuit-dir=datadir/circuits

NOTE

You would need to pass a bootstrap nodes and blockchain RPC endpoint based on the network you would like to join.

NOTE

We could skip --marketplace-address argument and rely on marketplace contract Auto-discovery.

After node is up and running, and your address has founds, you should be able to sell the storage using API.

You also can use Archivist App UI to sell the storage.

Archivist bootstrap node

Bootstrap nodes are used just to help peers with the initial nodes discovery and we need to run Archivist with just some basic options:

shell

archivist \
  --data-dir=datadir \
  --nat=any \
  --disc-port=8090

To get bootstrap node SPR we can use API call:

shell

curl -s localhost:8080/api/archivist/v1/debug/info | jq -r '.spr'

shell

spr:CiUIAhIhApd79-AxPqwRDmu7Pk-berTDtoIoMz0ovKjo85Tz8CUdEgIDARo8CicAJQgCEiECl3v34DE-rBEOa7s-T5t6tMO2gigzPSi8qOjzlPPwJR0Qjv_WtwYaCwoJBFxzjbKRAh-aKkYwRAIgCiTq5jBTaJJb6lUxN-0uNCj8lkV9AGY682D21kIAMiICIE1yxrjbDdiSCiARnS7I2zqJpXC2hOvjB4JoL9SAAk67

That SPR record then can be used then by other peers for initial nodes discovery.

We should keep in mind some important things about SPR record (see ENR):

It uses nodes public IP, discovery port (--disc-port) and private key (--net-privkey) for record creation
Specified data is signed on each run and will be changed but still contain specified node data when decoded
You can decode it by passing to the Archivist node at run and with --log-level=trace

For bootstrap node, it is required to forward just discovery port on your Internet router.

Run as a service in Linux

We can run Archivist as a service via systemd using following steps

Create an user for Archivist
shell
```
sudo useradd \
  --system \
  --home-dir /opt/archivist \
  --shell /usr/sbin/nologin \
  archivist
```
In case you would like to run commands using a created user, you could do it like following sudo -u archivist ls -la /opt/archivist.

Install Archivist using a script or build from sources

shell

# archivist with cirdl
curl -s https://get.archivist.storage/install.sh | INSTALL_DIR=/usr/local/bin CIRDL=true bash

Create directories

shell

sudo mkdir -p /opt/archivist/data
sudo mkdir -p /opt/archivist/logs

Create a configuration file

shell

sudo vi /opt/archivist/archivist.conf

toml

data-dir       = "/opt/archivist/data"
listen-addrs   = ["/ip4/0.0.0.0/tcp/8070"]
nat            = "extip:<Public IP>"
disc-port      = 8090
api-port       = 8080
bootstrap-node = [
  "spr:CiUIAhIhA5mg11LZgFQ4XzIRb1T5xw9muFW1ALNKTijyKhQmvKYXEgIDARpJCicAJQgCEiEDmaDXUtmAVDhfMhFvVPnHD2a4VbUAs0pOKPIqFCa8phcQl-XFxQYaCwoJBE4vqKqRAnU6GgsKCQROL6iqkQJ1OipHMEUCIQDfzVYbN6A_O4i29e_FtDDUo7GJS3bkXRQtoteYbPSFtgIgcc8Kgj2ggVJyK16EY9xi4bY2lpTTeNIRjvslXSRdN5w",
  "spr:CiUIAhIhAhmlZ1XaN44zPDuORyNJV8I79x2eSXt5-9AirVagKCAIEgIDARpJCicAJQgCEiECGaVnVdo3jjM8O45HI0lXwjv3HZ5Je3n70CKtVqAoIAgQ_OfFxQYaCwoJBAWhGBORAnVEGgsKCQQFoRgTkQJ1RCpHMEUCIQCgqSYPxyic9XmOcQYtJDKNprK_Uokz2UzjVZRnPYpOgQIgQ8m96ukov4XZG-j-XH53_vuoy3GkHuneUZ1Xe0luCxk",
  "spr:CiUIAhIhAnCcHA-aqMx--nwf8cJyZKJavc-PuYNKKROoW_5Q1JcREgIDARpJCicAJQgCEiECcJwcD5qozH76fB_xwnJkolq9z4-5g0opE6hb_lDUlxEQje7FxQYaCwoJBAXfFdCRAnVOGgsKCQQF3xXQkQJ1TipGMEQCIA22oUekTsDAtsIOyrgtkG702FJPn8Xd-ifEVTUSuu7fAiBv9YyAg9iKuYBhgZKsZBHYfX8l0sXvm80s6U__EGGY-g"
]
storage-quota  = "8gb"
block-ttl      = "24h"
log-level      = "info"

Make sure to use bootstrap nodes for the network you would like to join, update nat variable with a node Public IP and adjust other settings by your needs.

Change folders ownership and permissions

shell

sudo chown -R archivist:archivist /opt/archivist

Create systemd unit file

shell

sudo vi /lib/systemd/system/archivist.service

shell

[Unit]
Description=Archivist service
Documentation=https://docs.archivist.storage
After=local-fs.target network-online.target

[Service]
MemorySwapMax=0
TimeoutStartSec=infinity
Type=exec
User=archivist
Group=archivist
StateDirectory=archivist
ExecStart=/usr/local/bin/archivist --config-file="/opt/archivist/archivist.conf"
Restart=always
RestartSec=3
StandardOutput=append:/opt/archivist/logs/archivist.log
StandardError=append:/opt/archivist/logs/archivist.log

[Install]
WantedBy=multi-user.target

Check man systemd, man systemd.service and man systemd.directives for additional details.

Enable and start Archivist service

shell

sudo systemctl enable archivist
sudo systemctl start archivist

Check service status
shell
```
sudo systemctl status archivist
```

Enable logs rotation using logrotate

shell

sudo vi /etc/logrotate.d/archivist

logrotate

/opt/archivist/logs/*.log {
  daily
  missingok
  rotate 5
  copytruncate
  nocreate
  nomail
  dateext
  dateyesterday
}

Check the logs

shell

tail -f /opt/archivist/logs/archivist.log

Run as a service in Windows

This functionality is not supported yet 🚧

Using Docker

We also ship Archivist in Docker containers, which can be run on amd64 and arm64 platforms.

Docker entrypoint

Docker entrypoint, supports some additional options, which can be used for easier configuration:

ENV_PATH - path to the file, in form env=value which will be sourced and available for Archivist at run. That is useful for Kubernetes Pods configuration.
NAT_IP_AUTO - when set to true, will set ARCHIVIST_NAT variable with container internal IP address. It also is useful for Kubernetes Pods configuration, when we perform automated tests.
NAT_PUBLIC_IP_AUTO - used to set ARCHIVIST_NAT to public IP address using lookup services, like ip.archivist.storage. Can be used for Docker/Kubernetes to set public IP in auto mode.
ETH_PRIVATE_KEY - can be used to pass ethereum private key, which will be saved and passed as a value of the ARCHIVIST_ETH_PRIVATE_KEY variable. It should be considered as unsafe option and used for testing purposes only.
When we set prover sub-command, entrypoint will run cirdl tool to download ceremony files, required by Archivist storage node.
BOOTSTRAP_NODE_URL - Archivist node API URL in form of http://bootstrap:8080, to be used to get it's SPR as a bootstrap node. That is useful for Docker and Kubernetes configuration.
NETWORK - is a helper variable to simply a specific network join. It helps to automate BOOTSTRAP_NODE_FROM_URL variable.
BOOTSTRAP_NODE_FROM_URL - can be used to pass SPR nodes from an URL like spr.archivist.storage/testnet.
MARKETPLACE_ADDRESS_FROM_URL - can be used to pass a Marketplace contract address from an URL like marketplace.archivist.storage/testnet/latest.

Docker network

When we are running Archivist using Docker with default bridge network, it will create a double NAT:

One on the Docker side
Second on your Internet router

If your Internet router does not support Full Cone NAT, you might have an issue and peer discovery and data transport will not work or might work unexpected.

In that case, we should consider the following solutions:

Use host network for Docker, which is supported only in Linux
Run Using binary
Use VM/VPS in the Cloud to run Docker with bridge or host network

Run using Docker

And we basically can use same options we used for binary and additionally it is required to mount volumes and map the ports.

Archivist storage node

Create ethereum key file

example

CAUTION

Please use key generation service for demo purpose only.

shell

response=$(curl -s https://key.archivist.storage)
awk -F ': ' '/private/ {print $2}' <<<"${response}" > eth.key
awk -F ': ' '/address/ {print $2}' <<<"${response}" > eth.address
chmod 600 eth.key

Show your ethereum address:

shell

cat eth.address

0x412665aFAb17768cd9aACE6E00537Cc6D5524Da9

Run Archivist:

shell

docker run \
  --rm \
  -v $PWD/datadir:/datadir \
  -v $PWD/eth.key:/opt/eth.key \
  -p 8070:8070 \
  -p 8080:8080 \
  -p 8090:8090/udp \
  durabilitylabs/archivist-node:latest \
  archivist \
    --data-dir=/datadir \
    --bootstrap-node=spr:CiUIAhIhA5mg11LZgFQ4XzIRb1T5xw9muFW1ALNKTijyKhQmvKYXEgIDARpJCicAJQgCEiEDmaDXUtmAVDhfMhFvVPnHD2a4VbUAs0pOKPIqFCa8phcQl-XFxQYaCwoJBE4vqKqRAnU6GgsKCQROL6iqkQJ1OipHMEUCIQDfzVYbN6A_O4i29e_FtDDUo7GJS3bkXRQtoteYbPSFtgIgcc8Kgj2ggVJyK16EY9xi4bY2lpTTeNIRjvslXSRdN5w \
    --nat=any \
    --disc-port=8090 \
    --listen-addrs=/ip4/0.0.0.0/tcp/8070 \
    --api-cors-origin="*" \
    --api-bindaddr=0.0.0.0 \
    --api-port=8080 \
    persistence \
    --eth-provider=https://rpc.testnet.archivist.storage \
    --eth-private-key=/opt/eth.key \
    prover \
    --circuit-dir=/datadir/circuits

NOTE

You would need to pass a bootstrap nodes and blockchain RPC endpoint based on the network you would like to join.

NOTE

We could skip --marketplace-address argument and rely on marketplace contract Auto-discovery.

Using Docker Compose

For Docker Compose, it is more suitable to use environment variables for Archivist configuration and we can reuse commands from example above, for Docker.

Archivist storage node

Create ethereum key file

example

CAUTION

Please use key generation service for demo purpose only.

shell

response=$(curl -s https://key.archivist.storage)
awk -F ': ' '/private/ {print $2}' <<<"${response}" > eth.key
awk -F ': ' '/address/ {print $2}' <<<"${response}" > eth.address
chmod 600 eth.key

Show your ethereum address:

shell

cat eth.address

0x412665aFAb17768cd9aACE6E00537Cc6D5524Da9

Create docker-compose.yaml file:

yaml

services:
  archivist:
    image: durabilitylabs/archivist-node:latest
    container_name: archivist
    command:
      - archivist
      - persistence
      - prover
    environment:
      - ARCHIVIST_DATA_DIR=/datadir
      - NAT_PUBLIC_IP_AUTO=https://ip.archivist.storage
      - ARCHIVIST_DISC_PORT=8090
      - ARCHIVIST_LISTEN_ADDRS=/ip4/0.0.0.0/tcp/8070
      - ARCHIVIST_API_CORS_ORIGIN="*"
      - ARCHIVIST_API_PORT=8080
      - ARCHIVIST_API_BINDADDR=0.0.0.0
      - ARCHIVIST_ETH_PROVIDER=https://rpc.testnet.archivist.storage
      - ARCHIVIST_ETH_PRIVATE_KEY=/opt/eth.key
      - ARCHIVIST_CIRCUIT_DIR=/datadir/circuits
      - BOOTSTRAP_NODE_FROM_URL=https://spr.archivist.storage/testnet
    ports:
      - 8080:8080/tcp # API
      - 8090:8090/udp # Discovery
      - 8070:8070/tcp # Transport
    volumes:
      - ./datadir:/datadir
      - ./eth.key:/opt/eth.key
    logging:
      driver: json-file
      options:
        max-size: 100m
        max-file: 5

Run Archivist:
shell
```
docker compose up
```

NOTE

You would need to pass a bootstrap nodes and blockchain RPC endpoint based on the network you would like to join.

NOTE

We could skip ARCHIVIST_MARKETPLACE_ADDRESS variable and rely on marketplace contract Auto-discovery.

On Kubernetes

Helm chart code is available in helm-charts repository, but chart was not published yet.

How-tos

NAT Configuration

Use the --nat CLI flag to specify how your archivist node should handle NAT traversal. Below are the available options:

any(default): This option will automatically try to detect your public IP by checking the routing table or using UPnP/PMP NAT traversal techniques. If successful, it will use the detected public IP and port for the announce address.

upnp: This option exclusively uses UPnP to detect the public IP and create a port mapping entry, if your device supports UPnP.

pmp: This option uses only NAT-PMP to detect the public IP and create a port mapping entry, if your device supports NAT-PMP.

extIP:[Your Public IP]:Use this option if you want to manually specify an external IP address and port for the announce address. When selecting this option, you'll need to configure port forwarding on your router to ensure that incoming traffic is directed to the correct internal IP and port.

Port Forwarding

If you're running on a private network, you'll need to set up port forwarding to ensure seamless communication between the archivist node and its peers. It's also recommended to configure appropriate firewall rules for TCP and UDP traffic. While the specific steps required vary based on your router, they can be summarised as follows:

Find your public IP address by either visiting ip-archivist or running curl ip.archivist.storage
Identify your private IP address
Access your router's settings by entering its IP address (typically http://192.168.1.1) in your web browser
Sign in with administrator credentials and locate the port forwarding settings
Set up the discovery port forwarding rule with these settings:
- External Port: 8090
- Internal Port: 8090
- Protocol: UDP
- IP Address: Your device's private IP address
Set up the libp2p port forwarding rule with these settings:
- External Port: 8070
- Internal Port: 8070
- Protocol: TCP
- IP Address: Your device's private IP address

Determine your private IP

To determine your private IP address, run the appropriate command for your OS:

Linux:

shell

ip addr show | grep "inet " | grep -v 127.0.0.1

Windows:

shell

ipconfig | findstr /i "IPv4 Address"

MacOs:

shell

ifconfig | grep "inet " | grep -v 127.0.0.1

Known issues

Environment variables like ARCHIVIST_BOOTSTRAP_NODE and ARCHIVIST_LISTEN_ADDRS does not support multiple values. ↩︎
Sub-commands persistence and persistence prover can't be set via environment variables. ↩︎

Run Archivist ​

Configuration ​

Common information ​

Units ​

Logging ​

CLI options ​

Environment variables ​

Configuration file ​

Auto-discovery ​

Run ​

Using binary ​

Archivist node ​

Archivist node with marketplace support ​

Archivist storage node ​

Archivist bootstrap node ​

Run as a service in Linux ​

Run as a service in Windows ​

Using Docker ​

Docker entrypoint ​

Docker network ​

Run using Docker ​

Using Docker Compose ​

On Kubernetes ​

How-tos ​

NAT Configuration ​

Port Forwarding ​

Determine your private IP ​

Known issues ​

Run Archivist

Configuration

Common information

Units

Logging

CLI options

Environment variables

Configuration file

Auto-discovery

Run

Using binary

Archivist node

Archivist node with marketplace support

Archivist storage node

Archivist bootstrap node

Run as a service in Linux

Run as a service in Windows

Using Docker

Docker entrypoint

Docker network

Run using Docker

Using Docker Compose

On Kubernetes

How-tos

NAT Configuration

Port Forwarding

Determine your private IP

Known issues
